MagZoom TZM 6 Trinocular Zoom Stereo Microscope (1:6.7) with LED Illumination
Catalog No :
CAS Number :
Brand :
In Stock
Specifications:
| Application | microscopy | Warranty | 1 Year |
| Storage Temperature | Ambient | ||
| Product Type | Microscopes | ||
| Product Brand | Magnus | ||
| Product Grade | Analytical grade | ||
The MagZoom TZM 6 Trinocular Zoom Stereo Microscope is a compact, ergonomically designed stereomicroscope engineered for high-quality three-dimensional observation with integrated camera documentation capability. Featuring a trinocular viewing head, smooth zoom performance, and maintenance-free LED illumination, the TZM 6 is ideal for laboratories, teaching institutions, and industrial environments requiring both visual inspection and digital imaging.
With its adjustable working distance pillar stand, independent top and bottom LED lighting control, and wide magnification range, the TZM 6 provides excellent versatility for dissection, specimen analysis, and precision inspection workflows.
Key Features
- High-performance trinocular zoom stereo microscope for observation and imaging
- Smooth zoom system with 1:6.7 zoom ratio
- Compact ergonomic pillar stand with adjustable working distance
- Integrated transmitted and reflected maintenance-free LED illumination
- Independent intensity control for incident and transmitted lighting
- Standard magnification range 6.7× to 45×
- Built-in 45° trinocular observation tube for comfortable viewing and camera attachment
- Adjustable interpupillary distance (IPD) and diopter correction
- Rack-and-pinion focus drive with adjustable tension
- Supplied with stage plates, glass plate, clips, and dust cover
Optical Specifications
| Parameter | Specification |
|---|---|
| Microscope Type | Trinocular Zoom Stereo Microscope |
| Model | MagZoom TZM 6 |
| Zoom Ratio | 1:6.7 |
| Magnification Range (Standard) | 6.7× – 45× |
| Objective | Built-in 1× objective |
| Working Distance (Objective) | 100 mm |
| Eyepieces | Paired Widefield WF 10× / 22 mm |
| Viewing Head | Trinocular, 45° inclined |
| Interpupillary Distance (IPD) | 54 – 76 mm |
| Diopter Adjustment | ±5 mm |
Stand and Focus System
| Feature | Description |
|---|---|
| Stand Type | Ergonomic pillar stand |
| Adjustable Working Distance Range | 26 mm – 286 mm |
| Focus Mechanism | Rack-and-pinion focus drive |
| Focus Control | 360° rotatable with adjustable tension |
Illumination System
The MagZoom TZM 6 is equipped with:
- Integrated transmitted (bottom) LED illumination
- Integrated reflected (top) LED illumination
- Independent brightness regulation for each light source
- Universal power supply: 110–240V / 50Hz
LED illumination provides stable brightness, low heat output, and long service life.
Stage and Accessories Included
Standard complete set includes:
- 100 mm glass plate
- Black & white stage plate with clips
- Dust cover
- Complete microscope system ready for use
Applications
The MagZoom TZM 6 is suitable for:
- Biological dissection and specimen observation with imaging
- Parasitology and entomology laboratories
- Medical and educational teaching labs
- Electronics and component inspection with documentation
- Gemstone and jewelry evaluation
- Precision engineering and quality control inspection
The MagZoom TZM 6 Trinocular Zoom Stereo Microscope combines ergonomic design, integrated LED illumination, wide magnification capability, and trinocular imaging support in a compact stereomicroscope platform. With its flexible working distance, stable focusing system, and dual illumination control, it is an excellent solution for laboratories and industries requiring versatile stereoscopic observation with the option for camera-based documentation.
