BIOBASE Recirculating pump, Benchtop
Catalog No :
CAS Number :
Brand :
In Stock
Pump Head: 4
Circulating Pump Flow: 40L/min
Capcity:15L
Specifications:
| Storage Temperature | Ambient |
| Product Type | Pump |
| Product Brand | BIOBASE |
| Product Grade | Laboratory grade |
The BIOBASE SHZ-DIII Recirculating Pump is a compact, benchtop vacuum and circulation system designed to provide continuous suction and stable vacuum performance for laboratory applications such as rotary evaporation, distillation, filtration, and extraction.
With four independent pumping ports and gauges, this model supports simultaneous operation of multiple instruments, making it ideal for laboratories requiring efficient and reliable vacuum generation with anti-corrosive durability and recirculating water conservation.
Key Features
- Four-Port Design: Equipped with four vacuum gauges and four pumping heads for multi-user operation.
- Efficient Vacuum Generation: Achieves up to –0.098 MPa with a pumping speed of 10 L/min per port.
- Integrated Circulating System: Provides 40 L/min recirculating flow and 12 m pump lift.
- Anti-Corrosion Construction: Built from chemically resistant materials for compatibility with acids and solvents.
- Low Water Consumption: Closed-loop recirculation reduces environmental impact and utility costs.
- Compact Benchtop Design: Ideal for space-limited laboratories.
- Stable Performance: 370 W motor ensures consistent vacuum output for continuous operation.
- Optional Vacuum Control: For adjustable vacuum, a separate vacuum control instrument can be connected.
Technical Specifications
| Parameter | Description |
|---|---|
| Model | SHZ-DIII (Four gauge, four pumping) |
| Pump Head | 4 |
| Speed of Evacuation | 10 L/min per head |
| Ultimate Vacuum | –0.098 MPa |
| Circulating Pump Flow | 40 L/min |
| Pump Lift | 12 m |
| Material | Anti-corrosion construction |
| Power Consumption | 370 W |
| Reservoir Capacity | 15 L |
| Power Supply | AC 220 V 50/60 Hz (optional AC 110 V 60 Hz) |
| Package Size (W×D×H) | 460 × 370 × 570 mm |
| Gross Weight | 17 kg |
Applications
- Rotary evaporators and vacuum distillation systems.
- Vacuum filtration, solvent recovery, and extraction.
- Chemical, pharmaceutical, and biological research laboratories.
- Educational and industrial QC laboratories requiring multi-port vacuum supply.
Ordering Information
| Product | Model | Capacity | Power | Classification |
|---|---|---|---|---|
| BIOBASE Recirculating Pump, Benchtop | SHZ-DIII | 15 L | 370 W | Laboratory Vacuum Pump |
The BIOBASE SHZ-DIII Recirculating Pump delivers multi-port flexibility, stable vacuum performance, and water-saving operation in a durable benchtop design. Engineered for reliability in demanding laboratory workflows, it is the perfect companion for rotary evaporators, filtration systems, and general vacuum applications.
Note: The SHZ-DIII does not include adjustable vacuum control. For variable vacuum settings, pair with an external vacuum control instrument.
