Thermo Scientific™ Multiskan SkyHigh Microplate Spectrophotometer
Catalog No :
CAS Number :
Brand :
In Stock
Specifications:
| Application | Spectrophotometry | Warranty | 1 Year |
| Storage Temperature | Ambient | ||
| Product Type | Plate Reader | ||
| Product Brand | Thermo Fisher Scientific™ | ||
| Product Grade | Molecular Biology | ||
The Thermo Scientific™ Multiskan™ SkyHigh Microplate Spectrophotometer is a versatile and high-performance UV/Vis microplate reader, designed for photometric and turbidimetric applications, including DNA, RNA, and protein quantification. It offers full-spectrum measurements (200–1000 nm) with fast scan speeds and is optimized for endpoint, kinetic, and spectral assays.
The touchscreen model allows for stand-alone use with an intuitive interface and also integrates with Thermo Scientific™ SkanIt™ Software for advanced PC-controlled workflows. The system supports a wide range of microplate formats (6- to 384-well) and μDrop™ micro-volume plates, with optional cloud connectivity via Thermo Fisher Connect or Microsoft OneDrive for remote data access and management.
Key Features & Benefits
✅ Flexible Optical System
- Monochromator-based for free wavelength selection from 200 to 1000 nm
- <2.5 nm bandwidth and 1 nm resolution for high precision
- Photometric accuracy: 1.0% + 0.003 Abs (0–2.0 Abs)
✅ High Throughput & Speed
- Reads 96-well plate in 6 seconds and 384-well in 10 seconds
- Full spectrum scan in <10 seconds per well
- DNA spectrum in <3 seconds
✅ Multi-Format Compatibility
- Accepts 6-, 48-, 96-, and 384-well plates, including μDrop and μDrop Duo plates
- Maximum plate height: 19.5 mm (with lid)
- Supports top reading mode
✅ Integrated Shaking & Incubation
- Onboard linear shaking and temperature control from ambient +2°C to 45°C
- Suitable for temperature-sensitive or cell-based assays
✅ User-Friendly Interface
- High-resolution touchscreen for direct operation
- Ready-made protocols for UV-based DNA/RNA quantification and colorimetric protein assays
- Intuitive setup with Virtual Pipetting Tool and plate layout definition
✅ Advanced Software Integration
- Compatible with SkanIt™ Software (Research and FDA 21 CFR Part 11 editions)
- Unlimited installations with open license
- Available in multiple languages
- SkanIt Cloud Library with pre-configured protocols and application data
✅ Cloud Connectivity (Touchscreen Models)
- Optional integration with Thermo Fisher Connect and Microsoft OneDrive for secure data storage, sharing, and management.
Applications
- Nucleic acid quantification (DNA, RNA)
- Protein concentration determination (Bradford, BCA, Lowry, etc.)
- Cell proliferation, cytotoxicity, and viability assays
- Turbidimetric and colorimetric assays
- Kinetic enzyme assays
- Endpoint and spectral scanning workflows
Product Specifications
| Parameter | Specification |
|---|---|
| Catalog Number | A51119500C |
| Wavelength Range | 200–1000 nm |
| Wavelength Selection | Monochromator |
| Spectral Scanning Speed | <10 sec (200–1000 nm) |
| Photometric Accuracy | 1.0% + 0.003 Abs (0–2.0), 2.0% (2.0–2.5 Abs) |
| Linearity | 0–2.5 Abs, ±2% at 450 nm |
| Bandwidth | <2.5 nm |
| Resolution | 1 nm |
| Measurement Modes | Endpoint, Kinetic, Spectral |
| Microplate Formats | 6–48, 96, and 384-well plates; μDrop plates |
| Reading Mode | Top reading |
| Incubation Range | Ambient +2°C to 45°C |
| Shaking | Linear |
| Light Source | Xenon Flash Lamp |
| Software | SkanIt™ Software (open license, PC and touch compatible) |
| Languages (Touchscreen) | English, French, German, Spanish, Portuguese, Chinese, Japanese, Russian, Italian |
| Cloud Integration | Thermo Fisher Connect, Microsoft OneDrive (touchscreen models only) |
| Dimensions (W × D × H) | 29.5 × 44.5 × 26.5 cm (11.6 × 17.5 × 10.4 in.) |
| Weight | 10.8 kg (23.8 lb) |
| Unit Size | Each |
Why Choose the Multiskan SkyHigh?
✅ UV/Vis full-spectrum reader for a wide range of assays
✅ Rapid scan speeds and high photometric accuracy
✅ Touchscreen or PC software options for versatile operation
✅ Compatible with micro-volume and standard plate formats
✅ Ideal for multi-user environments with advanced data access options
The Multiskan SkyHigh is a future-ready microplate reader built for flexibility, speed, and sustainability, supporting modern life science research and assay development.
