Lovibond® XD7000 Vis Water Quality Spectrophotometer
Catalog No :
CAS Number :
Brand :
Availability :
In Stock
Specifications:
| Application | Water Quality Analysis | Warranty | 1 Year |
| Storage Temperature | Ambient | ||
| Product Type | Laboratory Equipment | ||
| Product Brand | Lovibond | ||
| Product Grade | Analytical grade | ||
Precision VIS Spectrophotometer for High-Performance Water Analysis
The Lovibond® XD7000 is a versatile VIS spectrophotometer designed for laboratories conducting comprehensive water quality testing. Featuring a wide spectral range, over 150 pre-programmed methods, and full GLP support, the XD7000 is engineered for precision, reliability, and intuitive operation. With automatic test and cuvette recognition, password-protected user levels, and extensive compatibility with Lovibond® reagents, the XD7000 is the dependable choice for regulated water analysis environments.
Downlaod Handbook of Methods Here
Key Features
- 150+ Pre-Programmed Methods: Ready-to-use methods compatible with Lovibond® reagents
- Automatic Method Recognition: Barcode-based identification prevents user error
- Automatic Cuvette Detection: Verifies correct cuvette type (round & rectangular)
- GLP-Compliant Features: Password-protected user access, calibration reminders, sample tracking
- Custom Method Capability: Program up to 100 user-defined methods using multi-wavelength inputs
- Large Color Display: 7” high contrast graphic interface
- Secure Data Handling: USB, Ethernet, SD card, and barcode scanner interfaces
- LIMS Compatible: Outputs .CSV and ASCII file formats
Applications
- Drinking Water & Wastewater Monitoring
- Boiler and Cooling Water Testing
- Disinfection and Chlorine Control
- Food and Beverage Water Analysis
- Galvanization & Process Water Monitoring
- Pool & Spa Compliance Testing
- Raw Water Treatment
Technical Specifications
| Specification | Details |
|---|---|
| Optical System | Grid monochromator with reference beam |
| Light Source | Tungsten halogen lamp |
| Wavelength Range | 320–1100 nm |
| Wavelength Accuracy | ±1 nm (Holmium standard) |
| Wavelength Resolution | 1 nm |
| Spectral Scope | 4 nm |
| Photometric Range | -3.3 to +3.3 Abs |
| Photometric Resolution | 0.001 Abs; 0.1% Transmission |
| Photometric Linearity | <1% up to 2.0 Abs (340–900 nm) |
| Photometric Reproducibility | 0.003 Abs (<0.6 Abs); 0.5% (0.6–2.0 Abs) |
| Stray Light | <0.1% T at 340 and 408 nm |
| Scan Speed | 700–2000 nm/min |
| Drift | <0.005 Abs/h (after 15 min warm-up) |
| Sample Types | Round and rectangular cuvettes (13–50 mm) |
| Interfaces | USB A & B, Ethernet, Barcode Scanner, SD card |
| Display | 7” high contrast color graphic display |
| Programmable Methods | Up to 100 user methods, 20 user profiles |
| Data Storage | ~5000 data sets, auto/manual save |
| Auto-Test Recognition | Internal barcode reader |
| Cuvette Recognition | 13, 16, 24 mm round / 10, 20, 50 mm rectangular |
| Power Supply | 100–240 V, 50/60 Hz |
| Dimensions (L × W × H) | 16.61 x 7.68 x 12.72 in |
| Compliance | CE, EN 60529, IEC 61000-4-3, EC Directive 2014/35/EC |
| Security | 3-level access (guest, user, admin) |
| GLP Support | Yes |
Included in Delivery
- XD7000 VIS Spectrophotometer
- Power supply cable and 4 × AA batteries
- 4 × 24 mm round cuvettes with lid + 1 zero cuvette (24 mm)
- 1 × 16 mm zero cuvette
- Quick Start Guide (24 languages)
- Full User Manual (8 languages)
- Warranty documentation
The Lovibond® XD7000 VIS Spectrophotometer delivers trusted precision and complete flexibility for regulated water testing applications. From disinfection control to industrial process water monitoring, its user-friendly interface, powerful optics, and full suite of GLP tools make it an essential component in any water quality lab.
Range
| Testparameter | Measuring Range | Method No. | Chemical Method |
|---|---|---|---|
| Alkalinity-m HR T | 5 - 500 mg/L CaCO3 | M31 | Acid / Indicator |
| Alkalinity-m T | 5 - 200 mg/L CaCO3 | M30 | Acid / Indicator |
| Alkalinity-p T | 5 - 500 mg/L CaCO3 | M35 | Acid / Indicator |
| Aluminium PP | 0.01 - 0.25 mg/L Al | M50 | Eriochrom Cyanine R |
| Aluminium T | 0.01 - 0.3 mg/L Al | M40 | Eriochrom Cyanine R |
| Ammonia HR TT | 1.0 - 50 mg/L N | M66 | Salicylate |
| Ammonia LR TT | 0.02 - 2.5 mg/L N | M65 | Salicylate |
| Ammonia PP | 0.01 - 0.8 mg/L N | M62 | Salicylate |
| Ammonia T | 0.02 - 1 mg/L N | M60 | Indophenole Blue |
| Arsenic | 0.02 - 0.6 mg/L As | M68 | Silver Diethyldithiocarbamate |
| Bromine 10 T | 0.1 - 3 mg/L Br2 | M78 | DPD |
| Bromine 50 T | 0.05 - 1 mg/L Br2 | M79 | DPD |
| Bromine PP | 0.05 - 4.5 mg/L Br2 | M81 | DPD |
| Bromine T | 0.05 - 13 mg/L Br2 | M80 | DPD |
| Cadmium M. TT | 0.025 - 0.75 mg/L Cd | M87 | Cadion |
Chloramine (M) PP | 0.02 - 4.5 | M63 | Indophenole method |
Chloride L (A) | 5.00 - 60 mg/L Cl- | M91 | Iron(III)-thiocyanate |
Chloride L (B) | 0.5 - 20 mg/L Cl- | M92 | Mercury Thiocyanate / Iron Nitrate |
| Chloride T | 0.5 - 25 mg/L Cl- | M90 | Silver Nitrate / Turbidity |
| Chlorine 10 T | 0.1 - 6 mg/L Cl2 | M98 | DPD |
| Chlorine 50 T | 0.02 - 0.5 mg/L Cl2 | M99 | DPD |
Chlorine (free) and Monochloramine | 0.02 - 4.50 mg/L Cl2 | M64 | Indophenole method |
| Chlorine dioxide 50 T | 0.05 - 1 mg/L ClO2 | M119 | DPD / Glycine |
| Chlorine dioxide PP | 0.04 - 3.8 mg/L ClO2 | M122 | DPD |
| Chlorine dioxide T | 0.02 - 11 mg/L ClO2 | M120 | DPD / Glycine |
| Chlorine HR 10 T | 0.1 - 10 mg/L Cl2 | M104 | DPD |
Chlorine HR (KI) T | 5 - 200 mg/L Cl2 | M105 | KI / Acid |
| Chlorine L | 0.02 - 4.0 mg/L Cl2 | M101 | DPD |
| Chlorine MR PP | 0.02 - 3.5 mg/L Cl2 | M113 | DPD |
| Chlorine PP | 0.02 - 2 mg/L Cl2 | M110 | DPD |
| Chlorine T | 0.01 - 6.0 mg/L Cl2 | M100 | DPD |
| Chromium 50 PP | 0.005 - 0.5 mg/L Cr | M124 | Diphenylcarbazide |
| Chromium PP | 0.02 - 2 mg/L Cr | M125 | Diphenylcarbazide |
| COD HR TT | 200 - 15000 mg/L COD | M132 | Dichromate / H2SO4 |
| COD LMR TT | 15 - 300 mg/L COD | M133 | Dichromate / H2SO4 |
| COD LR TT | 3 - 150 mg/L COD | M130 | Dichromate / H2SO4 |
| COD MR TT | 20 - 1500 mg/L COD | M131 | Dichromate / H2SO4 |
COD VLR TT | 2.0 - 60.0 mg/L COD | M134 | Dichromate / H2SO4 |
| Copper 50 T | 0.05 - 1 mg/L Cu | M149 | Biquinoline |
| Copper L | 0.05 - 4 mg/L Cu | M151 | Bicinchoninate |
| Copper PP | 0.05 - 5 mg/L Cu | M153 | Bicinchoninate |
| Copper T | 0.05 - 5 mg/L Cu | M150 | Biquinoline |
Copper VLR PP | 2 - 210 µg/L Cu | M152 | Porphyrine Indicator |
| CyA HR T | 10 - 200 mg/L CyA | M161 | Melamine |
| Cyanide 50 L | 0.005 - 0.2 mg/L CN- | M156 | Pyridine-barbituric Acid |
| Cyanide L | 0.01 - 0.5 mg/L CN- | M157 | Pyridine-barbituric Acid |
| CyA T | 10 - 160 mg/L CyA | M160 | Melamine |
| DEHA PP | 0.02 - 0.5 mg/L DEHA | M167 | PPST |
| DEHA T (L) | 0.02 - 0.5 mg/L DEHA | M165 | PPST |
Fluoride 2 L | 0.1 - 2 mg/L F- | M172 | SPADNS |
| Fluoride L | 0.05 - 2 mg/L F- | M170 | SPADNS |
| Formaldehyde 10 M. L | 1.00 - 5.00 mg/L HCHO | M175 | H2SO4 / Chromotropic acid |
| Formaldehyde 50 M. L | 0.02 - 1.00 mg/L HCHO | M176 | H2SO4 / Chromotropic acid |
| Formaldehyde M. TT | 0.1 - 5 mg/L HCHO | M177 | H2SO4 / Chromotropic acid |
| H2O2 50 T | 0.01 - 0.5 mg/L H2O2 | M209 | DPD / Catalyst |
| H2O2 HR L | 40 - 500 mg/L H2O2 | M214 | Titanium Tetrachloride / Acid |
| H2O2 LR L | 1 - 50 mg/L H2O2 | M213 | Titanium Tetrachloride / Acid |
| H2O2 T | 0.03 - 3 mg/L H2O2 | M210 | DPD / Catalyst |
Hardness Ca and Mg L | 0.05 - 4 mg/L CaCO3 | M199 | Calmagite |
Hardness Ca and Mg MR TT | 10 - 360 mg/L CaCO3 | M198 | Calmagite |
| Hardness Calcium (B) T | 20 - 500 mg/L CaCO3 | M191 | Murexide |
| Hardness Calcium (B) T | 50 - 900 mg/L CaCO3 | M190 | Murexide |
| Hardness total HR T | 20 - 500 mg/L CaCO3 | M201 | Metallphthaleine |
| Hardness total T | 2 - 50 mg/L CaCO3 | M200 | Metallphthaleine |
| Hazen 24 | 10 - 500 mg/L Pt | M204 | (APHA) Platinum Cobalt Standard Method |
| Hazen 50 | 10 - 500 mg/L Pt | M203 | (APHA) Platinum Cobalt Standard Method |
| Hydrazine L | 5 - 600 µg/L N2H4 | M206 | Dimethylaminobenzaldehyde |
| Hydrazine P | 0.05 - 0.5 mg/L N2H4 | M205 | Dimethylaminobenzaldehyde |
| Hypochlorite T | 0.2 - 17 % NaOCl | M212 | Potassium Iodide |
| Iron 10 T | 0.05 - 1 mg/L Fe | M218 | Ferrozine / Thioglycolate |
| Iron 50 PP | 0.01 - 1.5 mg/L Fe | M221 | 1,10-Phenanthroline |
| Iron 50 T | 0.01 - 0.5 mg/L Fe | M219 | Ferrozine / Thioglycolate |
| Iron (TPTZ) PP | 0.02 - 1.8 mg/L Fe | M223 | TPTZ |
| Iron HR L | 0.1 - 10 mg/L Fe | M227 | Thioglycolate |
| Iron in Mo PP (224) | 0.01 - 1.8 mg/L Fe | M224 | TPTZ |
| Iron LR L (A) | 0.03 - 2 mg/L Fe | M225 | Ferrozine / Thioglycolate |
| Iron LR L (B) | 0.03 - 2 mg/L Fe | M226 | Ferrozine / Thioglycolate |
| Iron PP | 0.02 - 3 mg/L Fe | M222 | 1,10-Phenanthroline |
| Iron T | 0.02 - 1 mg/L Fe | M220 | Ferrozine / Thioglycolate |
| KS4.3 T | 0.1 - 4 mmol/L KS4.3 | M20 | Acid / Indicator |
Lead | 0.01 - 5 mg/L Pb | M232 | 4-(2-Pyridylazo-)-resorcine |
| Lead (A) TT | 0.1 - 5 mg/L Pb | M234 | 4-(2-Pyridylazo-)-resorcine |
| Lead (B) TT | 0.1 - 5 mg/L Pb | M235 | 4-(2-Pyridylazo-)-resorcine |
| lodine T | 0.05 - 3.6 mg/L I | M215 | DPD |
| Manganese HR PP | 0.1 - 18 mg/L Mn | M243 | Periodate Oxidation |
| Manganese L | 0.05 - 5 mg/L Mn | M245 | Formaldoxime |
| Manganese LR PP | 0.01 - 0.7 mg/L Mn | M242 | PAN |
| Manganese T | 0.2 - 4 mg/L Mn | M240 | Formaldoxime |
| Molybdate HR L | 1 - 100 mg/L MoO4 | M254 | Thioglycolate |
| Molybdate HR PP | 0.3 - 40 mg/L Mo | M252 | Mercaptoacetic Acid |
| Molybdate LR PP | 0.03 - 3 mg/L Mo | M251 | Ternary Complex |
| Molybdate T | 1 - 50 mg/L MoO4 | M250 | Thioglycolate |
| Nickel 50 L | 0.02 - 1 mg/L Ni | M255 | Dimethylglyoxime |
| Nickel L | 0.2 - 7 mg/L Ni | M256 | Dimethylglyoxime |
Nitrate HR | 1.2 - 35 mg/L N | M268 | 2,6-Dimethylphenole |
Nitrate LR2 TT | 0.2 - 15 mg/L N | M266 | 2,6-Dimethylphenole |
| Nitrate LR TT | 0.5 - 14 mg/L N | M267 | 2,6-Dimethylphenole |
Nitrate MR PP | 1 - 30 mg/L NO3-N | M261 | Zinc Reduction |
| Nitrate T | 0.08 - 1 mg/L N | M260 | Zinc Reduction / NED |
| Nitrate TT | 1 - 30 mg/L N | M265 | Chromotropic Acid |
Nitrite HR PP | 2 - 250 mg/L NO2 - | M273 | Ferrous Sulfate Method |
| Nitrite HR TT | 0.3 - 3 mg/L N | M276 | Sulfanilic / Naphthylamine |
| Nitrite LR TT | 0.03 - 0.6 mg/L N | M275 | Sulfanilic / Naphthylamine |
| Nitrite PP | 0.01 - 0.3 mg/L N | M272 | Diazotation |
| Nitrite T | 0.01 - 0.5 mg/L N | M270 | N-(1-Naphthyl)-ethylendiamine |
Nitrite VHR L | 25 - 2500 mg/L NO2 - | M271 | Ferrous Sulfate Method |
| Oxygen active T | 0.1 - 10 mg/L O2 | M290 | DPD |
| Oxygen dissolved C | 10 - 1100 µg/L O2 | M292 | Rhodazine D TM |
| Ozone 50 T | 0.02 - 0.5 mg/L O3 | M299 | DPD / Glycine |
| Ozone PP | 0.015 - 1.2 mg/L O3 | M301 | DPD / Glycine |
| Ozone T | 0.02 - 2 mg/L O3 | M300 | DPD / Glycine |
| Phenol T | 0.1 - 5 mg/L C6H5OH | M315 | 4-Aminoantipyrine |
| PHMB T | 2 - 60 mg/L PHMB | M70 | Buffer / Indicator |
| Phosphate h. TT | 0.02 - 1.6 mg/L P | M325 | Phosphomolybdenum Blue |
| Phosphate HR C | 1.6 - 13 mg/L P | M327 | Vanadomolybdate |
| Phosphate HR L | 5 - 80 mg/L PO4 | M335 | Vanadomolybdate |
| Phosphate HR T | 0.33 - 26.09 mg/L P | M321 | Vanadomolybdate |
| Phosphate HR TT | 0.98 - 19.57 mg/L P | M322 | Vanadomolybdate |
| Phosphate LR C | 0.016 - 1.6 mg/L P | M328 | Stannous Chloride |
| Phosphate LR L | 0.1 - 10 mg/L PO4 | M334 | Phosphomolybic Acid / Ascorbic Acid |
| Phosphate LR T | 0.016 - 1.305 mg/L P | M320 | Phosphomolybdenum Blue |
| Phosphate PP | 0.02 - 0.815 mg/L P | M323 | Phosphomolybdenum Blue |
| Phosphate t. TT | 0.02 - 1.1 mg/L P | M326 | Phosphomolybdenum Blue |
| Phosphate total HR TT | 1.5 - 20 mg/L P | M318 | Phosphomolybdenum Blue |
| Phosphate total LR TT | 0.07 - 3 mg/L P | M317 | Phosphomolybdenum Blue |
| Phosphate TT | 0.02 - 1.63 mg/L P | M324 | Phosphomolybdenum Blue |
| Phosphonate PP | 0.02 - 125 mg/L PO4 | M316 | Persulfate UV Oxidation Method |
| pH-value HR T | 8.0 - 9.6 pH | M332 | Thymol Blue |
| pH value L | 6.5 - 8.4 pH | M331 | Phenol Red |
| pH-value LR T | 5.2 - 6.8 pH | M329 | Bromocresolpurple |
| pH-value T | 6.5 - 8.4 pH | M330 | Phenol Red |
| Polyacrylate L | 1 - 30 mg/L Polyacryl | M338 | Turbidity |
| Potassium T | 0.7 - 16 mg/L K | M340 | Tetraphenylborat Turbidity |
| SAC 436 nm | 0.5 - 50 m-1 | M345 | Direct Reading EN ISO 7887:1994 |
| SAC 525 nm | 0.5 - 50 m-1 | M346 | Direct Reading EN ISO 7887:1994 |
| SAC 620 nm | 0.5 - 50 m-1 | M347 | Direct Reading EN ISO 7887:1994 |
| Selenium | 0.05 - 2 mg/L Se | M363 | 3,3'-Diaminobenzidine in Toluene |
| Silicate HR PP | 1 - 100 mg/L SiO2 | M352 | Silicomolybdate |
| Silicate L | 0.1 - 8 mg/L SiO2 | M353 | Heteropolyblue |
| Silicate LR PP | 0.05 - 1.6 mg/L SiO2 | M351 | Heteropolyblue |
Silicate T | 0.05 - 4 mg/L SiO2 | M350 | Silicomolybdenum Blue |
| Silica VLR PP | 0.005 - 0.5 mg/L SiO2 | M349 | Heteropolyblue |
| Sulphate HR PP | 50 - 1000 | M361 | Bariumsulphate Turbidity |
| Sulphate PP | 5 - 100 mg/L SO4 2- | M360 | Bariumsulphate Turbidity |
| Sulphate T | 5 - 100 mg/L SO4 2- | M355 | Bariumsulphate Turbidity |
Sulphide L | 8 - 1400 mg/L S2- | M366 | Methylene Blue |
| Sulphide T | 0.04 - 0.5 mg/L S2- | M365 | DPD / Catalyst |
| Sulphite 10 T | 0.1 - 12 mg/L SO3 | M368 | DTNB |
| Sulphite T | 0.1 - 6 mg/L SO3 | M370 | DTNB |
| Surfactants M. (anion.) TT | 0.05 - 2 mg/L SDSA | M376 | Methylene Blue |
| Surfactants M. (cation.) TT | 0.05 - 1.5 mg/L CTAB | M378 | Disulphine Blue |
| Surfactants M. (not ionic) TT | 0.1 - 7.5 mg/L Triton X-100 | M377 | TBPE |
| Suspended solids 24 | 10 - 750 mg/L TSS | M384 | Turbidity / Attenuated Radiation Method |
| Suspended solids 50 | 10 - 750 mg/L TSS | M383 | Turbidity / Attenuated Radiation Method |
Tannin L | 0.5 - 20 mg/L Tannin | M389 | |
| TN HR 2 TT | 5 - 140 mg/L N | M284 | 2,6-Dimethylphenole |
| TN HR TT | 5 - 150 mg/L N | M281 | Persulphate Digestion |
| TN LR 2 TT | 0.5 - 14 mg/L N | M283 | 2,6-Dimethylphenole |
| TN LR TT | 0.5 - 25 mg/L N | M280 | Persulphate Digestion |
| TOC HR M. TT | 50 - 800 mg/L TOC | M381 | H2SO4 / Persulphate / Indicator |
| TOC LR M. TT | 5 - 80 mg/L TOC | M380 | H2SO4 / Persulphate / Indicator |
| Triazole PP | 1 - 16 mg/L Benzotriazole or Tolyltriazole | M388 | Catalyzed UV Digestion |
| Turbidity 24 | 10 - 1000 FAU | M386 | Attenuated Radiation Method |
| Turbidity 50 | 5 - 500 FAU | M385 | Attenuated Radiation Method |
| Urea T | 0.1 - 2.5 mg/L Urea | M390 | Indophenol / Urease |
| Zinc L | 0.1 - 2.5 mg/L Zn | M405 | Zincon / EDTA |
| Zinc T | 0.02 - 1 mg/L Zn | M400 | Zincon |
Product Specification not found.
Accessory Products
Add a Review
Customer Review
Showing
0
Of
0
