DLAB MS10-H500-Pro LCD Digital Magnetic Hotplate Stirrer With Ceramic Plate, 30L
Catalog No :
CAS Number :
Brand :
In Stock
Specifications:
| Application | Sample Processing | Warranty | 1 Year |
| Max Speed | 100 -1500rpm | ||
| Storage Temperature | Ambient | ||
| Product Type | Stirrer/Heater | ||
| Product Brand | DLAB | ||
| Product Grade | Analytical grade | ||
High-Volume, Precision-Controlled Magnetic Stirrer with Integrated LCD Interface
The MS10-H500-Pro is a powerful, digitally controlled magnetic hotplate stirrer engineered for high-volume laboratory mixing and heating. Featuring a 10-inch glass ceramic work plate, this unit offers excellent chemical resistance and efficient heat transfer. With LCD digital display, real-time SD card data logging, and external temperature probe (PT1000) support, the MS10-H500-Pro is ideal for applications requiring tight control over temperature and mixing in research and industrial labs.
Key Features
- Large Capacity: Mixes up to 30 L of water-based solutions
- Glass Ceramic Work Plate: Chemically resistant and thermally efficient 254 × 254 mm surface
- Advanced LCD Display: Monitors temperature and speed with ±0.1°C resolution
- External Sensor Compatible: PT1000 probe support for ±0.2°C temperature control accuracy
- Wide Speed Range: 100–1500 rpm with ±1 rpm resolution
- High Temperature Capability: Heats up to 500°C with 1°C increments
- Safety Features: “HOT” warning at >50°C, overheating protection at 540°C
- Programmable Timing: 1 minute to 99 hours 59 minutes
- SD Card Data Logging: Real-time recording of instrument operation
Applications
- Solution Preparation & Reagent Mixing
- Polymer & Material Synthesis
- Sample Digestion & Heating Protocols
- Pharmaceutical R&D and Industrial QC Labs
Technical Specifications
| Parameter | Value |
|---|---|
| Model | MS10-H500-Pro |
| Catalog Number | 8030132117 |
| Work Plate Size | 254 × 254 mm (10 inch) |
| Work Plate Material | Glass ceramic |
| Max Stirring Volume (H₂O) | 30 L |
| Speed Range | 100–1500 rpm (±1 rpm resolution) |
| Temperature Range | Room Temp. – 500°C (1°C increment) |
| Temp Control Accuracy | ±1°C (<100°C), ±1% (>100°C) |
| Temp Display Accuracy | ±0.1°C |
| External Sensor Support | PT1000 (±0.2°C accuracy) |
| Max Magnetic Bar Length | 80 mm |
| Motor Type | Brushless DC motor |
| Heating Output | 1500 W |
| Total Power | 1700 W |
| Voltage / Frequency | 100–120V / 200–240V, 50/60Hz |
| Dimensions (W × D × H) | 328 × 424 × 138 mm |
| Weight | 7.2 kg |
| Ambient Operating Temp. | 5–40°C |
| Ambient Humidity | ≤80% RH |
| Protection Class | IP20 |
The MS10-H500-Pro LCD Digital Magnetic Hotplate Stirrer delivers a powerful combination of precision, safety, and capacity, supporting the most demanding laboratory stirring and heating needs. Its large ceramic surface, advanced temperature control features, and SD card data tracking make it a reliable solution for research labs, academic institutions, and industrial workflows alike.
