FRITSCH PULVERISETTE™ MillControl Software for Windows
Catalog No :
CAS Number :
Brand :
In Stock
For automatic control and validation of grinding processes
Specifications:
| Application | Milling & Particle Sizing |
| Storage Temperature | Room Temperature |
| Product Type | Software |
| Product Brand | FRITSCH GmbH |
| Product Grade | Analytical grade |
The FRITSCH MillControl Software is an advanced process control and validation solution designed for the Planetary Mill PULVERISETTE™ 5 premium line and Planetary Micro Mill PULVERISETTE™ 7. It enables automated control, monitoring, and documentation of grinding processes, ensuring high reproducibility, process safety, and standardized operation.
By continuously tracking critical parameters such as rotational speed and power consumption, MillControl enhances operational reliability while supporting validated workflows in regulated laboratory environments.
Key Features
| Feature | Description |
|---|---|
| Automated mill control | Full control of grinding parameters and execution |
| Process validation | Ensures consistent and reproducible grinding conditions |
| Real-time monitoring | Tracks actual vs. set rotational speed and power consumption |
| SOP management | Create, save, and reuse standardized grinding procedures |
| Data logging & reporting | Generates structured reports and graphical analysis |
| Archive function | Stores and retrieves historical grinding data |
| Enhanced safety | Prevents overpressure, overheating, and system faults |
| EASY GTM integration | Enables in-situ pressure and temperature monitoring |
Advanced Functionality
Standard Operating Procedures (SOPs)
MillControl allows users to define multi-step grinding protocols, ensuring repeatability for routine workflows.
Example:
- 2 × 2 min at 900 rpm (6 min pauses)
- 3 × 1 min at 1100 rpm (8 min pause)
- 2 × 3 min at 600 rpm
These SOPs can be saved and reused, ensuring consistent execution across multiple runs and operators.
Process Monitoring & Validation
- Continuous monitoring of rotational speed and power consumption
- Graphical display of process parameters
- Standardized report generation for quality control
EASY GTM Integration (Optional)
When used with EASY GTM grinding bowls, the software transforms the mill into an analytical system capable of:
- Measuring gas pressure and temperature in real-time
- Monitoring thermal and chemical reactions during grinding
- Automatically adjusting operation to maintain safe parameters
Technical Details
| Parameter | Specification |
|---|---|
| Product type | Process control and validation software |
| Compatible instruments | PULVERISETTE™ 5 premium line, PULVERISETTE™ 7 |
| Operating system | Windows |
| Order No. | 83.5605.00 |
System Requirements
| Requirement | Specification |
|---|---|
| Operating system | Windows 7 or higher |
| Processor | Intel Core 2 Duo or better |
| RAM | Minimum 4 GB |
| Display | 1280 × 800 resolution |
| Storage | Approx. 10 MB (excluding data storage) |
Applications
- Laboratory process control and automation
- Standardization of grinding procedures
- Pharmaceutical and regulated environments
- Research and development laboratories
- Advanced materials and nanotechnology applications
The FRITSCH MillControl Software is a powerful digital solution that transforms planetary milling into a fully controlled, monitored, and validated process. By combining automation, real-time monitoring, SOP standardization, and data traceability, it significantly enhances process reliability, reproducibility, and safety.
When integrated with the EASY GTM system, it further elevates the milling process into an analytical platform, enabling deeper insights into material behavior during grinding—making it an essential tool for modern laboratories and advanced research environments.
