Thermo Scientific™ Orion™ Versa Star Pro™ Benchtop Meter Without Modules (pH, mV, Relative mV, ORP with Temperature)
Catalog No :
CAS Number :
Brand :
In Stock
Specifications:
| Application | Electrochemistry | Warranty | 1 Year |
| Storage Temperature | Ambient | ||
| Product Type | Benchtop meters | ||
| Product Brand | Thermo Fisher Scientific™ | ||
| Product Grade | Analytical grade | ||
The Thermo Scientific™ Orion™ Versa Star Pro™ Benchtop Meter Without Modules offers the ultimate in configurability and flexibility for electrochemical analysis. Designed for laboratories with evolving measurement needs, this advanced multiparameter meter allows users to customize up to four independent channels by selecting from a suite of plug-and-play Orion™ Versa Star measurement modules.
Ideal for pH, ISE, conductivity, dissolved oxygen (DO/RDO), and ORP analysis, the Versa Star Pro base unit provides intuitive operation, a color touchscreen interface, flexible data management, and password-protected method setup. It’s the perfect platform for high-throughput labs, regulated environments, educational institutions, and research facilities that require precise, multi-parameter electrochemical data collection.
Key Features and Benefits
- Modular Configuration: Accepts up to four Orion Versa Star measurement modules to build a fully customized system
- Color Graphic LCD Display: Large, backlit screen with adjustable text size and multilingual support
- Data Integrity & Security: Password-protected user accounts and customizable system access for audit compliance
- Flexible Read Modes: Auto-Read, Continuous, Timed, and Single-Shot modes with onscreen stability indicators
- Data Logging & Storage: Store up to 2,000 data points and 30 calibration records per parameter with full date/time stamps
- Easy Data Transfer: Export data to a printer or computer via USB or RS232 ports
- Method Storage: Save up to 10 methods per channel, including calibration data and measurement settings
- Durable Design: IP54-rated housing resists splashes and dust; can be wall-mounted or used with included stand
- Stirrer Control Support: Compatible with up to two meter-controlled stirrer probes for consistent mixing during measurements
- Broad Language Support: Includes English, French, Spanish, German, Italian, Chinese, Portuguese, and Korean
Compatible Modules (Sold Separately)
- pH Module: Measures pH, mV, relative mV, ORP with temperature
- pH/ISE Module: Adds ion concentration capability to pH measurements
- pH/LogR Module: Offers temperature compensation using LogR technology
- Conductivity Module: Measures conductivity, TDS, salinity, and resistivity
- Dissolved Oxygen Module (RDO/DO): Supports optical and polarographic DO probes
Technical Specifications
| Attribute | Specification |
|---|---|
| Catalog Number | VSTAR00 |
| Description | Versa Star Pro benchtop meter with stand (no modules) |
| Measurement Modes | pH, mV, Relative mV, ORP with Temperature (via modules) |
| Channels | Up to 4 (module-based) |
| Display | Color graphic LCD, user-customizable |
| Data Logging | 2,000 points with time/date stamp |
| Calibration Log | Stores 30 calibrations per parameter |
| Memory | Non-volatile (retains settings after power loss) |
| Power Supply | Universal AC adapter (100–240 V, 50/60 Hz) |
| Interface Ports | USB, RS232 |
| Languages | EN, FR, ES, DE, IT, CN, PT, KO |
| Temperature Range | 5°C to 45°C (41°F to 113°F) |
| Relative Humidity Range | 5 to 85% (non-condensing) |
| IP Rating | IP54 (dust and splash resistant) |
| Certifications/Compliance | CE, TUV 3-in-1, FCC Class A |
| Warranty | 3 Years |
| Unit Dimensions (L × W × H) | 28 × 24 × 10 cm (11 × 9.5 × 3.9 in) |
| Weight | 1.2 kg (2.5 lb) |
What’s Included
- Orion™ Versa Star Pro Benchtop Meter (base unit only)
- Electrode stand
- Universal power adapter
- Computer interface cable
- Quick start guide
- Literature CD
- Meter test certificate
Applications
- Environmental Monitoring: pH, conductivity, and DO analysis for water and wastewater testing
- Pharmaceutical and Industrial QC: ISE and pH measurements in raw materials and finished products
- Food and Beverage Testing: Electrochemical analysis of acidity, mineral content, and salt concentration
- Academic Research: Versatile system for teaching multi-parameter electrochemical methods
- High-Throughput Laboratories: Customizable workflows for multi-parameter measurements and regulatory compliance
Ordering Information
| Product Description | Catalog Number | Unit Size | Modules Included |
|---|---|---|---|
| Orion™ Versa Star Pro Benchtop Meter (Base) | VSTAR00 | Each | None |
The Thermo Scientific™ Orion™ Versa Star Pro™ Benchtop Meter Without Modules is the ideal solution for labs requiring flexibility, scalability, and precision. With its modular design, customizable channels, and powerful data handling capabilities, it offers a long-term platform for evolving electrochemical testing needs in regulated, industrial, or academic environments.
