Thermo Scientific™ Vanquish™ Split Sampler, FT

Catalog No :

CAS Number :

Brand :

Availability :

In Stock

This combination does not exist.

Specifications:

Application	HPLC	Warranty	1 Year
Storage Temperature	Ambient
Product Type	Analytical Instrument
Product Brand	Thermo Fisher Scientific™
Product Grade	Analytical grade

Overview
Resource

The Thermo Scientific™ Vanquish™ Split Sampler FT is a high-performance UHPLC autosampler designed to deliver exceptional injection precision, large sample capacity, and reliable high-throughput operation. Engineered for integration into the Vanquish Flex UHPLC platform, this sampler ensures unmatched retention time reproducibility, low carryover, and rugged performance under the most demanding UHPLC conditions—including system pressures up to 1500 bar (22,000 psi).

With advanced SmartInject™ technology, superior sample cooling, and automated barcode-driven sample handling, the Split Sampler FT provides a robust and flexible solution for laboratories requiring extended unattended operation, intensive sample sequences, and maximum data confidence.

Key Performance Features

1. SmartInject™ Technology for Unrivaled Precision

Ensures exceptional retention time stability
Protects column lifetime under ultra-high pressures (up to 1500 bar)
Enables smooth, reproducible injections for even the most sensitive UHPLC applications

2. Exceptional Injection Precision & Low Carryover

Injection precision:
- <0.25% area RSD for 1 µL
- Typically <0.5% area RSD for 0.5 µL
Carryover: <0.002% with caffeine
Ensures accurate quantitation and high-quality peak integration for trace impurities and low-level analytes

3. Huge Sample Capacity & High Throughput

Standard capacity: 216 vials (SBS footprint)
Expandable to 23 well plates (up to 8832 samples) using optional Vanquish™ Charger
Handles long sequences and multi-day unattended runs
Injection cycle time as fast as 8 seconds

Ideal for QC labs, stability studies, pharmaceutical workflows, and high-throughput screening.

4. Advanced Sample Cooling & Integrity Protection

Air-stream cooling maintains stable temperatures between 4°C to 40°C
Prevents deterioration of thermally sensitive samples
Ensures consistent sample conditions across long sequences

5. Automated & Intelligent Sample Handling

Built-in barcode reading for automated plate/vial recognition
Machine learning–based needle wash monitoring ensures optimal decontamination
Multiple vial formats and well-plate configurations supported
Flexible gradient delay volume customization for method transfer

6. Biocompatible Flow Path (Yes)

Suitable for biological samples, peptides, proteins, and metal-sensitive analytes
Titanium/PEEK-based components prevent adsorption and metal interaction

Compatible Sample Formats (Any four SBS footprint trays)

54 × 12 mm vials (≤1.5 mL)
96 × 6–8 mm vials (≤1.2 mL)
16 × 15 mm vials (≤4 mL)
9 × 22.5 mm vials (≤10 mL)
96- and 384-well plates (deep or shallow)
Carousel: 12 × 22.5 mm vials (≤10 mL) additionally

Technical Specifications

Parameter	Value
Description	Vanquish Split Sampler FT
Catalog Number	VF-A10-A-03
Biocompatible Version	Yes
Product Line	Vanquish Flex UHPLC Systems
Injection Type	Split Loop
Injection Volume Range	0.01–25 µL (0.01 µL steps); Optional: 0.01–100 µL; Multidraw: up to 250 µL or 1000 µL
Injection Cycle Time	As low as 8 sec
Injection Precision	<0.25% area RSD (1 µL)
Carryover	<0.002%
Sample Compartment Temperature	4°C to 40°C
Vial Bottom Detection	Yes (2.5 µL from 3 µL remaining)
Needle Wash Monitoring	Yes, using machine learning
PC Connection	USB 2.0, 3-port HUB
Dimensions (L × W × H)	290 × 420 × 620 mm
Weight	~17–20 kg
Unit Size	Each

The Thermo Scientific™ Vanquish™ Split Sampler FT delivers unparalleled injection precision, large sample capacity, advanced cooling, and high-throughput performance for UHPLC workflows. Featuring SmartInject™ technology, biocompatible flow paths, low carryover, and automated sample handling, it is ideal for demanding multi-day, high-volume analytical operations.
