Thermo Scientific™ Super-Nuova™ Multi-Position Digital Stirring Hotplate, 220/240 V 50/60 Hz
Catalog No :
CAS Number :
Brand :
In Stock
Specifications:
| Application | Sample Preparation | Warranty | 1 Year |
| Storage Temperature | Ambient | ||
| Product Type | Stirrer/Heater | ||
| Product Brand | Thermo Fisher Scientific™ | ||
| Product Grade | Analytical grade | ||
The Thermo Scientific™ Super-Nuova™ Multi-Position Digital Stirring Hotplate is a high-performance laboratory hotplate stirrer designed for life science, biotechnology, research, and high-throughput laboratory applications. It features four independently controlled stirring positions on a single heated ceramic top, enabling multiple samples to be processed simultaneously with consistent heating and stirring performance.
Designed for multi-user laboratories, the Super-Nuova™ stirring hotplate combines precise microprocessor control, digital temperature and speed display, user-programmable memory settings, and advanced safety features. Its ceramic top provides excellent chemical resistance, easy cleaning, and rapid heating, while the included external Type K probe supports accurate liquid temperature control.
Key Features
| Feature | Description |
|---|---|
| Four stirring positions | Allows simultaneous stirring of multiple samples on one heated ceramic surface |
| Microprocessor control | Ensures accurate and stable temperature and stirring speed setpoints |
| Digital display | Displays temperature or stirring speed for easy monitoring |
| Electronic feedback control | Monitors either top plate surface temperature or liquid temperature using the included external probe |
| Single-knob control | Controls both heat and speed, with a lock feature to prevent accidental changes |
| Four memory keys | Stores user-defined temperature and speed settings for repeatable workflows |
| Powerful magnetic stirring system | Helps prevent magnetic decoupling and supports reliable stirring performance |
| Stir Trac™ braking feature | Brings stir bars to an immediate stop and helps prevent runaway or decoupled stir bars |
| Ceramic top plate | Easy to clean, chemically resistant, and designed for fast boiling |
| RS-232 output | Allows output of time count, temperature setpoint, probe/top temperature, stirring setpoint, and actual speed |
Safety Features
| Safety Feature | Benefit |
|---|---|
| HOT TOP warning light | Activates when the heating surface is above 50°C to help prevent accidental burns |
| HOT OFF flashing alert | Continues flashing until the surface cools to 50°C or below, even after heating is turned off |
| Adjustable over-temperature protection | Helps prevent runaway heating conditions |
| Walk-away timer | Can shut off heating, stirring, or both after a user-defined interval |
| Spill-resistant design | Helps protect internal components from accidental spills |
| Rugged aluminum body | Low-profile cast aluminum construction improves stability and durability |
Applications
| Application Area | Typical Use |
|---|---|
| Life science laboratories | Sample heating, mixing, reagent preparation, and buffer preparation |
| Biotechnology workflows | Controlled stirring and heating of biological and chemical solutions |
| Research laboratories | Multi-sample heating and stirring for experimental workflows |
| Quality control laboratories | Repeatable sample preparation under controlled conditions |
| Educational laboratories | Demonstration and routine laboratory heating/stirring applications |
| High-volume processing labs | Simultaneous stirring of multiple vessels to improve throughput |
Technical Specifications
| Parameter | Specification |
|---|---|
| Product Name | Thermo Scientific™ Super-Nuova™ Multi-Position Digital Stirring Hotplate |
| Catalog Number | SP135930-33Q |
| Type | Stirring Hotplate |
| Top Plate Material | Ceramic |
| Top Plate Size | 10.25 × 10.25 in. |
| Number of Positions | Multiple / 4 stirring positions |
| Temperature Range | 1°C to 370°C |
| Temperature Adjustment | 1°C increments |
| Stirring Range | 50 to 1200 rpm |
| Maximum Sample Load | 16 kg / 35 lb |
| Electrical Requirements | 220/240 V, 50/60 Hz |
| Voltage | 220/240 V |
| Amperage | 6.1 A |
| Wattage | 1450 W |
| Display | Digital |
| Shape | Square |
| Dimensions | 16.2 × 11.3 × 4 in. / 41.1 × 28.7 × 10.2 cm |
| Weight | 20.5 lb / 9.3 kg |
| Shipping Weight | 20.5 lb / 9.3 kg |
| Operating Environment | 0°C to 27°C, 80% relative humidity, non-condensing |
| Certifications / Compliance | cCSAus, CE |
| Unit Size | Each |
| Warranty | 2 years |
Included Accessories
| Included Item | Description |
|---|---|
| Detachable line cord and plug | For power connection |
| 6 in. Type K probe | External temperature probe for liquid temperature monitoring |
| Stir bar | Included with stirring models |
Unique Advantages
| Advantage | Benefit |
|---|---|
| Multi-position stirring on one hotplate | Saves bench space while supporting multiple simultaneous samples |
| Independent stirring control | Improves flexibility for multi-sample workflows |
| Memory settings | Allows frequent methods to be recalled quickly and consistently |
| Remote probe calibration | Enables temperature control to be aligned with external standards |
| Advanced safety alerts | Helps protect users in busy laboratory environments |
| Ceramic heating surface | Offers chemical resistance, easy cleaning, and efficient heating |
The Thermo Scientific™ Super-Nuova™ Multi-Position Digital Stirring Hotplate is a reliable, high-capacity hotplate stirrer for laboratories that require accurate heating, strong stirring performance, and safe multi-sample processing. With four stirring positions, digital control, memory functions, external probe compatibility, RS-232 output, and advanced safety features, it is well suited for life science, biotechnology, research, quality control, and high-volume laboratory workflows.
