BEHR Behrotest® KEX 5000F/TK Complete Soxhlet Extraction System (5000 mL Extractor with 10,000 mL Round Flask and Titanium Condenser)
Catalog No :
CAS Number :
Brand :
In Stock
Specifications:
| Application | Determination of Total Fats | Warranty | 1 Year |
| Storage Temperature | Ambient | ||
| Product Type | Laboratory Equipment | ||
| Product Brand | Behr Labor-Technik | ||
| Product Grade | Analytical grade | ||
The Behr KEX 5000F/TK Extraction Apparatus is a high-capacity system designed for classical Soxhlet and fat extraction applications in analytical, industrial, and research laboratories. Built for reliability and performance, this apparatus enables efficient extraction of fats, oils, and other extractable compounds from a wide variety of sample matrices.
Equipped with a titanium condenser, a 5000 mL extraction vessel, and a 10,000 mL round-bottom flask, the system offers exceptional chemical resistance, thermal stability, and scalability for demanding extraction workflows.
When combined with Behr hydrolysis units, the KEX 5000F/TK supports acid digestion prior to extraction, allowing for the determination of total fat content according to the Weibull-Stoldt method.
Key Features
- High-Volume Extraction – Accommodates up to 5000 mL of extractable sample, suitable for large or concentrated material analysis.
- Titanium Condenser – Offers superior corrosion resistance and thermal performance, ideal for aggressive solvents.
- 10,000 mL Round Bottom Flask – Provides generous solvent capacity for extended extraction cycles and complete sample recovery.
- Integrated Magnetic Stirring – Ensures homogeneous heating and uniform extraction efficiency.
- Continuously Variable Heating Mantle – Precise temperature control for optimal solvent evaporation and recovery.
- Innovative “Böckerhoff” Lifting Tube Design – Guarantees consistent results across all sample positions.
- Stopcock Extractor (F Model) – Eliminates the need for post-extraction distillation, saving time and solvent.
- Stable Stand Design – Allows secure positioning of condensers and extraction adapters during and between runs.
Technical Specifications
| Parameter | Specification |
|---|---|
| Model | KEX 5000F/TK |
| Item Number | B00696159 |
| Extraction Capacity | 5000 mL |
| Round Bottom Flask | 10,000 mL |
| Condenser Material | Titanium |
| Power Consumption | 1200 W |
| Sample Positions | 1 |
| Controller | No |
| Packaging Quantity | 1 |
| Extraction Type | Soxhlet / Fat Extraction |
Applications
The KEX 5000F/TK is ideal for laboratories performing quantitative extraction and fat determination in complex matrices.
Typical Areas of Use:
- Food and Beverage Analysis
- Oil and Fat Determination
- Feed and Agricultural Analysis
- Environmental and Soil Testing
- Chemical and Plastics Industry
- Research and Development Laboratories
Analytes and Parameters:
Extract content, total fat, free fat, oil content, PCBs, residual resin, pesticides, dioxins, chloride content, bound fat, caffeine, fiber, and other organic extractives.
Sample Types:
Ash, soil, fish and fish products, meat and meat products, feed, coffee, compost, milk and dairy products, nutritional formulations, oilseeds, tea, cellulose, and more.
Benefits
- Enables reproducible extraction results even for complex or high-fat samples.
- Supports both solvent and acid hydrolysis extraction methods.
- Built from durable, corrosion-resistant materials for long-term laboratory use.
- Designed for operator safety and ease of handling with secure condenser and adapter mounts.
- Modular and compatible with other Behr extraction and digestion systems.
The Behr KEX 5000F/TK provides a powerful and flexible platform for large-scale Soxhlet extractions, combining precision, durability, and user-friendly operation. Its robust titanium condenser and high-volume setup make it an essential choice for laboratories requiring reliable fat, oil, and extract content analysis in diverse matrices.
