BEHR behrosog 3® Scrubber with vacuum pump 40 L/h
Catalog No :
CAS Number :
Brand :
In Stock
Specifications:
| Application | Nitrogen Determination | Warranty | 1 Year |
| Storage Temperature | Ambient | ||
| Product Type | Laboratory Equipment | ||
| Product Brand | Behr Labor-Technik | ||
| Product Grade | Analytical grade | ||
The BEHR behrosog 3® Process Extraction System is a compact and highly efficient two-stage scrubber system designed to safely extract and neutralize aggressive acid fumes. Ideal for laboratories performing Kjeldahl digestion or other acid-based procedures, it ensures that no toxic fumes are released into the environment. Equipped with a pre-separator and safety stage, the system efficiently captures and neutralizes hazardous vapors.
This system operates independently of a water supply, reducing installation requirements and running costs, while maintaining a continuous and variable intake flow. For samples with high water content, an optional additional cooling system (ACS) can be attached for enhanced performance.
Key Features
- System Type: Two-stage process extraction (pre-separator + safety stage)
- Pump Delivery Rate: 40 L/min (without backpressure)
- Vacuum Pump Included: Yes, integrated 40 L/min vacuum pump
- Cooling & Neutralization: Built-in condensation and neutralization stages prevent toxic emissions
- Optional Accessory: ACS Additional Cooling System for samples with high water content
- Power Requirements: 230 VAC, 50/60 Hz, 80 W
- Weight: 18 kg
- Dimensions: 38 × 34 × 40 cm (W × D × H)
- Environmentally Safe: No need for water connection; low running costs
- Indicator: Compatible with Bromothymol Blue for process monitoring
Applications
- Kjeldahl nitrogen determination
- Acid digestion procedures requiring fume neutralization
- Safe handling of aggressive acids in laboratory and research environments
- Industrial or educational laboratories requiring a compact fume extraction system
Ordering Guide
| Type | Product Description | Art. No. |
|---|---|---|
| behrosog 3 Scrubber | Scrubber with suction pump (40 L/min), cooling stage, neutralisation stage, and drip catcher | B00217925 |
| ACS | Additional cooling system for behrosog 3, for samples with high water content | B00217927 |
The BEHR behrosog 3® Process Extraction System combines safety, efficiency, and ease of use for laboratories handling acid fumes. Its two-stage extraction system, integrated vacuum pump, and optional cooling module make it an ideal solution for preventing hazardous emissions while maintaining reliable performance.
