The Thermo Scientific™ iCAP™ PRO ICP-OES Radial system delivers robust, high-throughput, and interference-resistant elemental analysis for laboratories requiring dependable trace metal quantification. Engineered with a compact benchtop footprint, this instrument combines vertical plasma geometry, thermostated optics, CID detection, and advanced gas control to produce exceptional analytical stability across a wide range of matrices.

Designed for high productivity in environmental, food, pharmaceutical, mining, petrochemical, academic, and industrial QC laboratories, the iCAP PRO ICP-OES Radial provides superior multi-element performance compared to single-element AAS systems. Its automated workflows, durable construction, and intuitive software make it ideal for both routine and demanding applications.

Key Features

High Robustness & Matrix Tolerance

• Vertical torch configuration prevents salt buildup, enhances plasma stability, and improves tolerance to challenging matrices.
• Corrosion-resistant inner torch box extends system life and reduces maintenance needs.

High Sensitivity & Spectral Resolution

• Purged echelle polychromator with thermostatic temperature control ensures long-term wavelength stability.
• Cross-dispersing prism enables a fine 7 pm spectral bandpass for reduced spectral interferences.
• CID821 detector delivers full-spectrum simultaneous detection from 167 to 852 nm.

Stable Plasma Generation

• Solid-state 27.12 MHz RF generator optimized at 1150 W for high-energy, consistent plasma.
• Three independent mass flow controllers precisely regulate nebulizer, plasma, and auxiliary gases.

Improved Workflow & Ease of Use

• Qtegra™ ISDS software simplifies method creation, data acquisition, and batch processing.
• Built-in diagnostics, real-time signal monitoring, and health tracking features minimize downtime.
• Quick-release semi-demountable torch enables fast cleaning and replacement.

Safety & Reliability

• Interlock drain sensor automatically shuts down system if sample leaks occur.
• ACT label certification supports sustainable laboratory operation with reduced environmental impact.

Included System Components

The iCAP PRO ICP-OES Radial package includes the following:

1. ICP-OES Instrument Core

• iCAP PRO simultaneous echelle spectrometer
• CID821 random-access full-wavelength detector
• Vertical EMT radial torch
• Thermostatically controlled polychromator
• Built-in RF generator (27 MHz, 1150 W)

2. Gas and Sample Handling

• Three-channel peristaltic pump (0 or 45 rpm) for internal standard addition and sample delivery
• Three mass flow controllers (MFCs):
  • Plasma gas: 12.5 L/min (fixed)
  • Auxiliary gas: 0.5 L/min (fixed)
  • Nebulizer gas: 0.3–0.8 L/min (tunable)

3. Standard Sampling Kit

• Concentric glass nebulizer
• Glass cyclonic spray chamber
• EMT Radial torch body
• 1.5 mm bore quartz center tube

4. Software

• Thermo Scientific™ Qtegra™ Intelligent Scientific Data Solution™ (ISDS):
  • Automated optimization
  • Wavelength selection
  • Method editing and batch analysis
  • Integrated QC tools
  • Post-processing and reporting

5. Built-In Safety & Maintenance Tools

• Interlock drain system
• Torch alignment aids
• Real-time plasma monitoring
• System diagnostic tools
• Preventive maintenance alerts

Specifications

The Thermo Scientific™ iCAP™ PRO ICP-OES Radial is a powerful, reliable, and user-friendly solution for laboratories requiring high-quality, simultaneous multi-element analysis. Its rugged design, advanced optics, precise gas control, and intelligent software platform ensure exceptional accuracy, long-term stability, and reduced operating costs. Backed by ACT environmental certification, the iCAP PRO supports both scientific performance and sustainability goals. It is an ideal choice for high-throughput elemental workflows across diverse industries, offering superior performance compared to conventional AAS systems.
